PSA Nitrogen Generator 99.9% Purity Low Power Consumption

Name: PSA Nitrogen Generator 999 Purity Low Power Consumption
Brand: Joshining
Price: 1 USD

Brand Name : Joshining

Model Number : PN-200-39

Certification : CE,ASME,DNV,CCS,BV,ABS,LR

Place of Origin : Suzhou

MOQ : Negotiation

Price : Negotiated

Payment Terms : L/C,T/T,Western Union,MoneyGram

Supply Ability : 80 sets per year

Delivery Time : within 2-3 months

Packaging Details : Normal exporting size

Name : PSA Nitrogen Generator

Working pressure : 6-7 bar

Advantage : Low Power Consumption

Purity : 99.9-99.99%

Technology : Pressure Swing Adsorption

Contact Now

PSA Nitrogen Generator with Low Power Consumption

Product Attributes

Attribute	Value
Name	PSA Nitrogen Generator
Working pressure	6-7 bar
Advantage	Low Power Consumption
Purity	99.9-99.99%
Technology	Pressure Swing Adsorption

Product Description

Our PSA Nitrogen Generator utilizes pressure swing adsorption principles at normal temperatures, using clean compressed air as raw material and high-quality carbon molecular sieve (CMS) from Japan & Germany as the adsorbent, ensuring a working life exceeding 20 years.

Key Benefits

German Technology: Proprietary technology developed through German collaboration with optimized performance advantages
Automated Operation: Fully automated system requiring no personnel for operation
Low Power Consumption: Optimized design for efficient compressed air usage and maximum nitrogen production

PSA Technology Explained

Pressure Swing Adsorption (PSA) is a mature technology dating back to the 1970s, with thousands of installations worldwide. Our systems have been supplied to customers in over 56 countries.

PSA Nitrogen Generator 99.9% Purity Low Power Consumption

The process utilizes two vessels filled with Carbon Molecular Sieves (CMS):

Adsorption: Compressed air passes through CMS vessel where oxygen is adsorbed, producing nitrogen
Desorption: When CMS becomes saturated, the process switches to the second vessel while the first regenerates
Regeneration: Nitrogen purges the saturated vessel to regenerate the CMS for the next cycle

Technical Specifications

Model	Capacity (Nm³/h)	Purity	Power (KW)	Overall Size (mm)
PN-3-39	3	99.9%	0.5	1800×1400×1500
PN-5-29	5	99.5%	0.5	1800×1400×1500
PN-30-49	30	99.99%	0.5	2400×1900×2200
PN-100-49	100	99.99%	0.5	3500×1500×2800

Note: Complete specifications available upon request. Contact Since Gas System Co., Ltd for more information.
